Fresh Air Handling Unit (TFU)
Fresh air is a basic need in any building for the health of its occupants. Our Eurovent Certified Range of Fresh Air Handling Units (FAHUs) infuse treated fresh air from outside into the indoor spaces. The unit treats the outside fresh air, makes it clean and comfortable before circulating it in the required places. It offers cooling, heating, humidification, dehumidification, efficient filtration, sound attenuation, and many more features.
Certified by
Technical Specifications
| Capacity (CFM) | 700 – 100000 |
| Material of Construction (MOC) | GI/Al/SS-304/SS-316 |
| Panel | Double Skin |
| Panel Thickness | 50 mm (25 mm & 43±2 mm – Optional) |
| Outer Sheet Thickness | 0.6 mm (0.8 mm, 1.0 mm, 1.2 mm, & 1.6 mm – Optional) |
| Inner Sheet Thickness | 0.6 mm (0.8 mm, 1.0 mm, 1.2 mm, & 1.6 mm – Optional) |
| Outer Sheet Coating | Pre-Coated GI (Powder coated GI, Al, SS-304, & SS-316 – Optional) |
| Inner Sheet Coating | Plain GI (Pre-coated GI, Powder coated GI, Al, SS-304, & SS-316 – Optional) |
| Insulation | Puff (Rockwool & Fiber Glass – Optional) |
| Insulation Density | 40 kg/m3 (48 kg/m3, 64 kg/m3, & 96 kg/m3 – Optional) |
| Profile | Thermal Break Al Profile |
| Fan Type | Direct Driven (Belt Driven – Optional) |
| Motor | IE-2, IE-3, IE-4, IE-5 & BLDC – Optional |
| Coil | AHRI & UL Certified Chilled Water coil |
| Coil Header | MS Header (Copper Header – Optional) |
| Material Of Fins | Heresite coated (Hydrophilic Coating optional) |
| Drain Tray | 20G SS304 tray insulated with 13 mm closed cell Nitrile insulation |
| Drain Tray (Optional) | 18G SS304 as primary tray and 24G GI as secondary tray duly insulated with 25 mm closed cell PUF insulation. |
| Filters | Pre-filter & Fine Filter (HEPA optional) |
| Unit Base | 80 mm/100 mm/1.2 mm/2 mm thick GSS Base/MS/Al Optional) |
Construction
Supply Stream
- Fresh air intake section with manually operated FA damper in Al construction
- Filter section with 50 mm thick (EU-4) box type prefilter
- HRW section with heat recovery wheel of suitable diameter
- Heat pipe section with precool & reheat wraparound type heat pipe
- Coil section with 8 row deep chilled water cooling coil
- Section with UVGI lamp
- Fan section with Plug type fan with EC motor
- Manually operated SA damper in Al construction
Return Stream
- Return air intake section with manually operated RA damper in Al construction
- Filter section with a 50 mm thick (EU-4) box type prefilter
- HRW section with heat recovery wheel of suitable
- Fan section with Plug type fan with EC motor
- Manually operated EA damper in Al construction
Features & Benefits
- Customized treated fresh air solution
- Heat recovery and smart automation (Optional)
- Aluminium or SS casing (Optional)
- BMS compatible
- PHI-CELL®/REME-HALO® to neutralize microbes (Optional)
- Infuses O2 in the controlled spaces to counter SBS/BRI
- Energy efficient
- Reduces particulates (Dust,Dander and Pollen) in the air Diminishes harmful gases (VOCs & Odors)
- Demand controlled ventilation
Applications
- Hospital
- Pharmaceuticals
- Food Industry
- Commercial & Residential Buildings
- Laboratories
- Cleanroom
- Hotel
- Institutes
